The cooling tower is a heat dissipation device, which uses water and air to exchange heat and cold to generate steam, and the steam volatilizes to take away heat to achieve evaporation heat dissipation, convective heat transfer and radiation heat transfer to dissipate industrial or refrigeration air conditioning. The waste heat generated in the water is used to reduce the water temperature of the evaporative cooling device to ensure the normal operation of the system..
| Model | T=28°C cooling water（m3/h） | T=27°C cooling water（m3/h） | Main Size(mm) | Blowing Rate(m3/h) | Diameter of Fan(mm) | Motor Power(KW) | Inlet Water Pressure(Kpa) | Diameter(m) | |
| Total Height | Max.Diameter | ||||||||
| MC-20 | 20 | 24 | 2123 | 1460 | 12400 | 800 | 0.8 | 20 | 1.5 |
| MC-30 | 30 | 35 | 2342 | 1912 | 18000 | 1200 | 0.8 | 22.1 | 1.8 |
| MC-50 | 50 | 57 | 2830 | 2215 | 28000 | 1400 | 1.5 | 26.5 | 2.1 |
| MC-60 | 60 | 68 | 3080 | 2215 | 32300 | 1400 | 1.5 | 29 | 2.1 |
| MC-80 | 80 | 92 | 3344 | 2629 | 43400 | 1600 | 2.2 | 30.3 | 2.5 |
| MC-100 | 100 | 114 | 3294 | 3134 | 56000 | 1800 | 3 | 28.6 | 3 |
| MC-125 | 125 | 142 | 3544 | 3134 | 67200 | 1800 | 4 | 31.5 | 3 |
| MC-150 | 150 | 171 | 3533 | 3732 | 8400 | 2400 | 4 | 29 | 3.6 |
